NHRP network IDs are locally significant and can be different. It makes sense from a deployment and maintenance perspective to use unique network ID numbers (using the ip nhrp network-id command) across all routers in a DMVPN network, but it is not necessary that they be the same. https://www.cisco.com/c/en/us/td/docs/ios-xml/ios/sec_conn_dmvpn/configuration/15-mt/sec-conn-dmvpn-15-mt-book/sec-conn-dmvpn-dmvpn.html

The reason is that by default, the SSL VPN clients use split tunneling, which means they only send traffic destined for the corporate network through the VPN tunnel, and use their local gateway for other traffic, such as browsing the internet. This means that when they search for their IP address on a browser, they will see their local IP address, not the IP address of the ASA.

To change this behavior, you need to configure the Group Policy on the ASA to tunnel all networks, which means that all traffic from the SSL VPN clients will go through the VPN tunnel, regardless of the destination. This way, when they search for their IP address on a browser, they will see the IP address of the ASA, which is 3.3.3.3.

To configure tunnel all networks under Group Policy, you can use either ASDM or CLI. For example, using ASDM, you can follow these steps1:

Choose Configuration > Remote Access VPN > Network (Client) Access > Group Policies.

Select the group policy that you want to modify and click Edit.

In the Edit Internal Group Policy window, choose Advanced > Split Tunneling.

In the Policy drop-down list, choose Tunnel All Networks.

Click OK and then Apply.

Using CLI, you can enter these commands:

ciscoasa(config)# group-policy attributes ciscoasa(config-group-policy)# split-tunnel-policy tunnelall

https://www.cisco.com/c/en/us/td/docs/ios-xml/ios/sec_conn_ike2vpn/configuration/15-mt/sec-flex-vpn-15-mt-book/sec-flex-spoke.html

https://www.cisco.com/c/en/us/support/docs/routers/3600-series-multiservice-platforms/91193-rtr-ipsec-internet-connect.html

HSRP (Hot Standby Router Protocol). HSRP is a Cisco proprietary protocol that provides stateful failover for IPsec virtual private networks (VPNs). It is used to create a virtual router in order to provide redundancy in the event of an IPsec VPN failure. HSRP works by assigning a single primary router to manage the connection and forwarding traffic to the secondary router if the primary router fails.

https://www.cisco.com/c/en/us/td/docs/ios-xml/ios/sec_conn_vpnav/configuration/15-mt/sec-vpn-availability-15-mt-book/sec-state-fail-ipsec.html

https://www.cisco.com/c/en/us/support/docs/security/anyconnect-secure-mobility-client/200533-AnyConnect-Configure-Basic-SSLVPN-for-I.html

https://www.cisco.com/c/en/us/support/docs/security/dynamic-multipoint-vpn-dmvpn/111976-dmvpn-troubleshoot-00.html
