This scenario requires unequal load distribution based on server capacity. The newer servers must receive more connections than the older ones, while still dynamically accounting for active connection counts.

According to BIG-IP Administration: Data Plane Configuration documentation:

Weighted Least Connections (member) combines:

Connection awareness (least connections)

Administrator-defined weights (ratios) to reflect server capacity

Pool members with higher weights receive proportionally more new connections than members with lower weights, even when using the same load balancing algorithm.

Why B is correct:

Allows assigning higher weights to newer servers and lower weights to older servers

Ensures smarter traffic distribution based on both capacity and real-time load

Why the other options are incorrect:

A. Global AvailabilityUsed for disaster recovery and site failover, not intra-pool load distribution.

C. Round RobinDistributes connections evenly without considering server capacity.

D. Least Connections (member)Balances only by current connection count and does not account for differences in server performance or capacity.

Correct Resolution:

Use Weighted Least Connections (member) and assign higher weights to newer servers so they receive more traffic while protecting older servers from overload.

By default, BIG-IP load balancing algorithms (such as Round Robin) distribute connections evenly across all available pool members. However, persistence profiles override normal load balancing decisions by forcing subsequent connections from a client to be sent to the same pool member.

According to the BIG-IP Administration: Data Plane Configuration documentation:

Persistence creates a client-to-server mapping that is honored before load balancing algorithms are applied.

When persistence is enabled, BIG-IP may repeatedly select the same pool member even if others are available.

This directly alters load balancing behavior.

Why the other options are incorrect:

A. Adding a OneConnect profileOneConnect optimizes server-side TCP connections but does not change which pool member is selected.

B. Enabling SNAT automapSNAT affects source address translation, not pool member selection.

C. Enabling a fallback host in the HTTP profileA fallback host is only used when no pool members are available.

Correct Resolution:

Adding a persistence profile alters load balancing behavior by maintaining client affinity to a specific pool member.

When a failover occurs in a standard BIG-IP High Availability (HA) pair, the newly active device takes over the floating IP addresses (Virtual Servers, Self IPs). By default, the new active device sends Gratuitous ARP (GARP) messages to the local network switch to inform it that these IP addresses are now associated with its own physical MAC addresses. However, network switches and intermediate routers often have ARP aging timers or security features that may delay the updating of their ARP tables, leading to "black-holed" traffic or dropped packets for several seconds or minutes until the network infrastructure correctly relearns the new path.

To eliminate this delay and ensure a seamless transition, a BIG-IP Administrator should Configure MAC Masquerade. MAC Masquerade allows the administrator to assign a unique, "virtual" MAC address to a specific traffic group. Instead of using the hardware-burned MAC address of the individual appliance, the active device uses this shared virtual MAC address for all communication involving floating IPs. When a failover occurs, the standby device assumes control of the traffic group and begins using the exact same virtual MAC address. Because the MAC address associated with the VIPs never changes from the switch's perspective, there is no need for the switch to update its MAC address table or for the surrounding infrastructure to update its ARP caches. This effectively eliminates the "stabilization period" reported by users, as the data plane transition happens almost instantaneously at Layer 2, maintaining continuous traffic flow without being hindered by external network re-convergence times.

When a single IP address (Virtual Server) must host multiple hostnames (e.g., site1.com, site2.com) over HTTPS, the BIG-IP must be able to present the correct SSL certificate for each site during the initial handshake. This requirement is handled by a technology called Server Name Indication (SNI).

To implement this on the BIG-IP, the administrator must use a Client SSL profile because the encryption is occurring between the user (Client) and the Virtual Server. Within the Client SSL profile settings, there is a field called Server Name. By creating multiple Client SSL profiles—each with a different "Server Name" (the hostname) and its corresponding certificate—and attaching them all to the same Virtual Server, the BIG-IP can inspect the SNI extension in the client's "Client Hello" packet. It then selects the specific profile that matches the requested hostname.

Option A is incorrect because "Client Name" is not the standard field name used for SNI hostname matching in the profile. Options B and C refer to Server SSL profiles, which manage the connection between the BIG-IP and the backend servers. While Server SSL profiles also have a "Server Name" field (used to send SNI to a backend server), the requirement here is to provide encrypted communication for "users" accessing the virtual server, which definitively requires a Client-side SSL configuration.

WAN-optimized TCP profiles improve performance for high-latency Internet clients, while LAN profiles are optimal for backend servers.

SNAT Automap is a common configuration that replaces the client's original source IP address with one of the BIG-IP's self IP addresses. This ensures that the backend servers send return traffic back through the BIG-IP, which is necessary for the ADC to process the traffic correctly. However, a side effect of SNAT is that the backend servers only see the BIG-IP's IP in their logs, losing visibility into the true identity of the client.

To resolve this while still using SNAT for routing purposes, the administrator must configure the BIG-IP to "pass" the client's IP address at the application layer. This is achieved by using an HTTP Profile with the Insert X-Forwarded-For setting enabled. When this profile is applied to the Virtual Server, the BIG-IP intercepts the HTTP request, adds a header (X-Forwarded-For) containing the client's original IP, and then forwards the modified request to the server. The backend web server can then be configured to read this header and log the original client IP instead of the BIG-IP's SNAT address.

Other options are incorrect for this requirement. Performance (HTTP) (Option A) is a virtual server type optimized for speed but often lacks the full Layer 7 header manipulation capabilities of a Standard Virtual Server. SNAT Pool with the client IP (Option C) is technically impossible as SNAT pools use static, pre-defined IPs. There is no such thing as an HTTP Transparent profile (Option D) in standard BIG-IP administration for this purpose. The X-Forwarded-For header insertion within the HTTP profile is the standard procedural method for maintaining client visibility in SNAT-enabled environments.

The issue described is a classic symptom of asymmetric routing, which frequently occurs when the BIG-IP system and the back-end servers reside on the same subnet (often referred to as a "one-arm" deployment).

The Routing Problem: By default, the BIG-IP system preserves the original client source IP address when forwarding traffic to a pool member. If the server is in the same subnet as the client or if the server's default gateway is not the BIG-IP, the server will attempt to send its response directly back to the client’s IP address, bypassing the BIG-IP.

Stateful Failure: Since the BIG-IP is a Full Proxy, it maintains a state table. Because the response packet never returns through the BIG-IP, the system cannot complete the three-way handshake or manage the application session, resulting in a connection failure for the user.

The Solution (SNAT): Enabling Source Network Address Translation (SNAT) solves this by changing the source IP address of the request to an IP address owned by the BIG-IP (typically a self-IP).

Requirement for Subnet Alignment: To ensure the server sends the response back to the BIG-IP, the translation address must be reachable. By using a self-IP configured in the same subnet as the servers, the BIG-IP ensures that the server sees the request coming from a local "neighbor." The server will then naturally send the response back to that self-IP, allowing the BIG-IP to translate the packet back and forward it to the client.

Why other options are incorrect:

A: Disabling address translation would ensure the server-side traffic uses the client IP, making asymmetric routing inevitable in this scenario.

B: This is technically contradictory; "Auto Map" specifically uses existing self-IPs and does not require or use a "SNAT pool" configuration.

C: While using a specific translation address can work, it does not inherently guarantee the Layer 2/Layer 3 reachability mentioned in the scenario as effectively as ensuring the self-IP is correctly placed in the server's subnet.

The issue of "lost shopping carts" in an ecommerce environment is a classic symptom of a missing or improperly configured Persistence Profile. In modern web applications, session data—such as items added to a cart—is often stored locally on the specific web server that initially handled the user's request. If the BIG-IP system load balances a user's subsequent request (like clicking "Checkout") to a different server among the 50 webservers, the new server will not have the session data, and the user will appear to have an empty cart.

While Least Connections (node) is an efficient load balancing algorithm, it makes a new decision for every connection unless persistence is enabled. To resolve this, the administrator must implement a persistence mechanism. HTTP Cookie Persistence (Option A) is the industry standard for web applications. By assigning a cookie persistence profile to the Virtual Server, the BIG-IP inserts a unique cookie into the HTTP response. When the user's browser returns that cookie in future requests, the BIG-IP identifies the specific server that handled the first request and consistently directs the user back to that same server for the duration of their session.

Sip_info (Option B) is a persistence method for VOIP traffic and is not applicable to web traffic. Ratio load balancing (Options C and D) merely changes the distribution frequency but still does not guarantee that a specific user will stay on the same server across multiple requests. Therefore, adding a cookie persistence profile is the direct procedural fix to maintain session state and ensure ecommerce functionality.

F5 provides several pre-configured (built-in) TCP profiles designed to optimize traffic for different network conditions. When an administrator is looking to improve general performance but does not have a specific, narrow use case (like strictly mobile or strictly long-haul WAN), the f5-tcp-progressive profile is the recommended starting point.

The f5-tcp-progressive profile is designed as a modern, high-performance replacement for the older default TCP settings. It incorporates several advanced congestion control algorithms and buffer management techniques that allow it to adapt dynamically to varying network latencies and packet loss scenarios. Unlike f5-tcp-legacy (Option A), which uses older, less efficient stacks, the progressive profile leverages modern TMM (Traffic Management Microkernel) optimizations.

While f5-tcp-mobile (Option B) is highly effective for high-loss cellular networks and f5-tcp-wan (Option D) is optimized for high-latency long-distance links, they can sometimes be too aggressive or poorly suited for standard campus or data center environments. The f5-tcp-progressive profile acts as a "best-of-all-worlds" template that typically provides an immediate performance boost for most web applications by improving window scaling and fast-retransmit behavior. Therefore, it is the procedural "first step" in TCP performance tuning before moving to more specialized, niche profiles.

When dealing with heterogeneous server hardware where some servers are more powerful than others, a dynamic load balancing method that accounts for both current load and server capacity is required. The Weighted Least Connections (member) method is the most appropriate choice. This method works by tracking the number of active connections to each pool member and then "weighting" that number based on a user-defined Ratio value assigned to the member. For example, the administrator can assign a higher Ratio to the three newer, more powerful servers and a lower Ratio to the two older servers. The BIG-IP then uses a formula to calculate which server should receive the next connection, ensuring that the newer servers handle a proportionately larger share of the total concurrent connections.

Standard Round Robin (Option C) would be ineffective because it distributes connections strictly sequentially (1, 2, 3, 4, 5) without regard for the servers' capacity or current load, which would eventually overwhelm the older servers. Least Connections (member) (Option D) is better than Round Robin because it picks the server with the fewest active connections, but it still assumes all servers are equal; it would try to keep the connection counts identical across all 5 servers, which would still stress the older hardware more than the new. Global Availability (Option B) is a GSLB (DNS-based) method used for multi-site redundancy, not for local pool member load balancing. By using Weighted Least Connections, the administrator achieves a balance where the more capable servers take the brunt of the work while the older servers are utilized only to their specific safe capacity.
