Fortinet FCSS - SD-WAN 7.4 Architect FCSS_SDW_AR-7.4 Exam Dumps: Updated Questions & Answers (September 2025)

When all SD-WAN members on a given interface are detected as "dead" (failed health checks), FortiGate will bring down the corresponding physical interface (e.g., port5) to prevent further traffic from being sent over a non-functional path. This helps to ensure that no traffic is black-holed and allows for proper failover.

The FortiManager SD-WAN overlay template preview, as described in the document, indicates:

"When the device is acting as a hub, the configuration enables the sending of ADVPN shortcut offers to spokes. This means the hub can facilitate on-demand dynamic shortcut tunnel creation between spokes, improving performance for branch-to-branch communication by bypassing the hub for inter-branch traffic after initial discovery."

Such a role is critical in scalable ADVPN topologies, enabling hub devices to optimize overlays dynamically.

After using the SD-WAN overlay template, two mandatory post-run tasks remain:

"First, administrators must create and assign policy packages to branch devices, as security and access policies are not included in overlay templates. Second, SD-WAN rules must be configured so that traffic can be matched and steered appropriately through the established overlays. Neglecting either task results in ungoverned traffic or inefficient routing, undermining the benefits of SD-WAN."

Templates automate topology, but policy and rule definition are critical for operational effectiveness.

When referencing a zone in a static route, FortiGate’s behavior is described as:

"Referencing a zone in a static route causes FortiGate to install a static route for each member interface of the zone. This enables ECMP (Equal-Cost Multi-Path) and load balancing where supported and ensures that traffic can be steered over any valid zone member according to SD-WAN rules or standard routing."

This mechanism is fundamental to Fortinet’s implementation of SD-WAN and simplifies large, multi-interface deployments.

When planning to deploy a large number of branches (e.g., 50), Fortinet recommends several preparatory steps to simplify and automate the rollout. Creating model devices allows you to predefine configurations and settings that can be cloned or adapted for each branch, saving time and minimizing manual errors. Preparing a Zero Touch Provisioning (ZTP) template enables automatic onboarding and provisioning of new FortiGates as soon as they come online, reducing manual intervention. Lastly, creating a policy blueprint allows for standardized policy deployment across all branches, ensuring consistent security and SD-WAN rule enforcement. This holistic approach streamlines the deployment process, allows for rapid scaling, and ensures that all devices are configured according to corporate policy from day one.

Traffic steering decisions in SD-WAN are based on both SD-WAN member priorities and route metrics. The guide states:

"If HUB1-VPN3 has a higher member configuration priority (lower numerical value) or a route with a lower priority value (which actually represents higher precedence in routing), it will be chosen over HUB1-VPN1, even if an SD-WAN rule would otherwise match HUB1-VPN1. These dual factors—member configuration and route table priority—govern traffic egress decisions."

Administrators should carefully align route and SD-WAN member priorities for predictable path selection.

Event logs (from the exhibit) show how traffic is matched to SD-WAN rules and routed. The log output indicates that voice traffic is being routed through the HUB1-VPN3 tunnel. This matches SD-WAN's application-aware steering, which uses dynamic performance metrics to select the optimal path.

When using FortiManager to configure SD-WAN members for multiple branches, it's crucial that you do not combine direct installation targets and metadata variables for the same SD-WAN member. From the FortiManager logs and the SD-WAN 7.4 documentation:

"If you define a metadata variable for an SD-WAN member interface, you must not also specify an explicit installation target for that member. This is because the metadata variable will be resolved to a specific interface during template application, making the static assignment redundant or conflicting. FortiManager will display a 'Copy Failed' or similar error if both are defined, requiring the administrator to remove the installation target and rely solely on the metadata-driven assignment."

This approach supports scalable deployments with device-specific mapping handled dynamically by FortiManager.

In the SD-WAN GUI, the absence of members in a zone is visually represented, and the Fortinet guide confirms:

"If a zone such as overlay-factories contains no members, it will be displayed as empty in the SD-WAN GUI. This may occur when the zone is reserved for future expansion, or if members have been temporarily removed for maintenance or reconfiguration. Traffic cannot be steered via an empty zone until at least one SD-WAN member is added."

Such visual cues help operators quickly assess configuration status and readiness.

For SD-WAN deployments that span multiple regions—where most traffic is intra-region and there is no requirement for inter-region ADVPN—the best practice is to use IBGP with BGP on loopback interfaces for routing within each region and EBGP between the regions. This approach ensures robust and scalable routing, isolates regional routing domains, and enables policy control at region boundaries. BGP on loopback is preferred for its reliability and flexibility, as it enables peering that is not tied to specific physical interfaces. EBGP between regions allows each region to maintain independent routing policies and summarization, optimizing performance and manageability. By separating IBGP (intra-region) and EBGP (inter-region), you create a modular architecture that scales easily and simplifies fault isolation and troubleshooting.
